Data Structures and Data Frames

Preflight

Ensure that RStudio/R is open with the appropriate packages installed (tidyverse)

Learning Questions

This lesson might sound like it’s going to be a bit dry: “Why should I care about data types and structures?”
IF YOU UNDERSTAND YOUR DATA, AND YOU UNDERSTAND HOW R SEES YOUR DATA, YOUR ANALYSIS WILL BE MUCH EASIER AND MORE EFFECTIVE
Some questions you might have had before this session may include those on the slide:
- How can I read data in R?
- What are the basic data types in R?
- How do I represent categorical information in R?
This session aims to help you answer those

Learning Objectives

In this section, you’ll be learning about the data types in R:
- WHAT DATA IS
You’ll be learning about data structures:
- WHAT DATA IS BUILT INTO - HOW IT IS ARRANGED
You’ll also learn how to find out what type/structure a particular piece of data has
- Putting it together, you’ll see how R’s data types and structures relate to the types of data that you work with, yourself.
- This will help you work much more fluently in R
In particular, we’ll be working with DATA FRAMES - this is the workhorse data structure in R and, when you use R, you will see a lot of them.

Data Types and Structures in `R`

R is MOSTLY USED FOR DATA ANALYSIS
R is set up with key, core data types designed to help you work with your own data
A lot of the time, R focuses on tabular data.
R is very powerful when dealing with tabular data
INTERACTIVE DEMO
SWITCH TO THE CONSOLE
Let’s start by making a toy dataset.
We’ll eventually save this in your data/ directory, with the name feline-data.csv
Use the console in RStudio
We’ll create a new variable called cats
- This holds a data.frame

cats <- data.frame(coat = c("calico", "black", "tabby"),
                    weight = c(2.1, 5.0, 3.2),
                    likes_catnip = c(1, 0, 1))

We can now save the content of the variable cats as a CSV (comma-separated variable) file.
- We use the write.csv() function
- It is useful to call argument names explicitly so that the code is more readable

write.csv(cats, file = "data/feline-data.csv", row.names = FALSE)

We’re writing the cats data out to file
- file specifies the filename we’re writing to
- row.names tells R not to give the rows in the table a name
USE THE FILES TAB/VIEW FILES TO VIEW THE CONTENTS OF THE NEW FILE
This is a plain text file, and you could have created it using a text editor like Nano or Notepad.
- The first row is the header row
- Each individual cat gets its own row
- Each column is a different kind of data
- Each column is separated by a comma
We can load the data from a CSV file in a similar way to how we write it
- We can use the read.csv() function
- Inspect the dataset by using the variable name

cats <- read.csv(file = "data/feline-data.csv")
cats
    coat weight likes_catnip
1 calico    2.1            1
2  black    5.0            0
3  tabby    3.2            1

THINK ABOUT THE DATA TYPES Are they all the same?
- NO coat is text; weight is some real value (in kg or pounds, maybe), and likes_string looks like it should be TRUE/FALSE but is represented as 1s and 0s
- DOES IT MAKE SENSE TO WORK WITH EACH OF THESE ELEMENTS OF DATA AS IF THEY’RE THE SAME THING? (No)
Let’s explore our dataset
EXTRACT A COLUMN FROM A TABLE
- Use $ notation in the console
- NOTE THE AUTOCOMPLETION

> cats$weight
[1] 2.1 5.0 3.2
> cats$coat
[1] "calico" "black"  "tabby"

WHAT DID R RETURN?
- A vector (1D ordered collection) of numbers or character strings
WE CAN OPERATE ON THESE VECTORS
- Vectors are an important concept, and R is largely built so that operations on vectors are central to data analysis.
Suppose that we discover the scales used to weigh the cats is miscalibrated
- Every cat weight is underestimated by 2kg
- We can correct all the weights at once

> cats$weight + 2
[1] 4.1 7.0 5.2

Suppose we want to make a string out of each of the coat types:

> paste("My cat is", cats$coat)
[1] "My cat is calico" "My cat is black"  "My cat is tabby"

What if we try to combine these columns?

> cats$weight + cats$coat
Error in cats$weight + cats$coat :
  non-numeric argument to binary operator

WE HIT AN ERROR
- You probably already realised that wasn’t going to work, because adding “calico” to “2.1” is nonsense.
  - You already have intuition about this
- THESE DATA TYPES ARE NOT COMPATIBLE for addition
- R’s data types reflect the ways in which data is expected to interact
UNDERSTANDING HOW YOUR OWN DATA MAP TO R’s DATA TYPES IS KEY
- It’s very important to understand how R sees your data (you want R to see your data the same way you do)
- Many problems in R come down to incompatibilities between data and data types.

What Data Types Do You Expect?

ASK THE STUDENTS
- What data types would you expect to see?
- What data types do you think you would WANT OR NEED, from your own experience?
SPEND A COUPLE OF MINUTES ON THIS
- The difference between a data type and a data structure

Data Types in `R`

R’s data types are atomic: they are FUNDAMENTAL AND EVERYTHING ELSE IS BUILT UP FROM THEM, the same way matter is built up from atoms
- In particular, all the data structures are built up from data types
There are only FIVE DATA TYPES in R (though one is split into two…) - three that matter here and two we won’t deal with
- logical: Boolean, True/False (also 1/0)
- numeric: anything that’s a number on the number line; two types of number are supported: integer and double (real)
- character: text data - readable symbols
The other two are less relevant to you and we’ll not deal with them much today
- complex: complex numbers, defined on the 2D plane
- raw: binary data
LET’S LEARN A BIT MORE ABOUT THEM IN THE DEMO
We can ask what type of data something is with the typeof() function

> typeof(cats$weight)
[1] "double"
> typeof(TRUE)
[1] "logical"
> typeof(3.14)
[1] "double"
> typeof(1)
[1] "double"

This might seem unintuitive: 1 is an integer
- But R treats all numbers as doubles (i.e. “Real” numbers) by default
- To force R to see a value as an integer, we need to add an L suffix

> typeof(1L)
[1] "integer"
> typeof(cats$coat)
[1] "character"
> typeof("Irn Bru")
[1] "character"

No matter how complicated your analysis gets, all data in R is interpreted as one of these basic data types.
- R - like most computer languages - is strict about data types, and this has important consequences.
SUPPOSE OUR FRIEND WANTS TO ADD DETAILS OF THEIR OWN CAT TO OUR DATASET
- We can create a new dataframe to hold this data

> additional_cat <- data.frame(coat = "tabby", weight = "2.3 or 2.4", likes_catnip = 1)
> additional_cat
   coat     weight likes_catnip
1 tabby 2.3 or 2.4

We can “stack” dataframes using the function rbind

> cats2 <- rbind(cats, additional_cat)
> cats2
    coat     weight likes_catnip
1 calico        2.1            1
2  black          5            0
3  tabby        3.2            1
4  tabby 2.3 or 2.4            1

Initially, everything looks OK - but we’ve silently caused some problems.
- Let’s look at the data type of cats$weight in the two dataframes

> typeof(cats$weight)
[1] "double"
> typeof(cats2$weight)
[1] "character"

Our friend gave us a different data type in the weight column, and this means we can no longer do the same weight adjustment (adding on 2kg) that we did before:

> cats2$weight + 2
Error in cats2$weight + 2 : non-numeric argument to binary operator

A Quick Note About Dataframes

Any column in a dataframe can contain only one datatype.
Initially, the datatype of cats$weight was double
When we added the new cat, the data in that column was character - i.e. a string
Because we can always represent a number as a string, but we can’t always represent a string as a number, R chose to coerce the datatype from double to character for that column.
INTERACTIVE DEMO
We can look at the structure of a dataframe using the str() function

> str(cats)
'data.frame': 3 obs. of  3 variables:
 $ coat        : chr  "calico" "black" "tabby"
 $ weight      : num  2.1 5 3.2
 $ likes_catnip: int  1 0 1
> str(cats2)
'data.frame': 4 obs. of  3 variables:
 $ coat        : chr  "calico" "black" "tabby" "tabby"
 $ weight      : chr  "2.1" "5" "3.2" "2.3 or 2.4"
 $ likes_catnip: num  1 0 1 1

Here the str() function tells us that cats and cats2 are both data.frames - a very common kind of data structure in R
- All data frames are composed of rows and columns.
- Every column has the same number of rows
- Every column has one and only one data type
- Each column can be a different data type
To understand data.frames, a bit better, let’s meet a different data structure called a vector

Vectors

These are the MOST COMMON DATA STRUCTURE
- Vectors are an ordered collection of data values
- Vectors can contain ONLY A SINGLE DATA TYPE (atomic vectors)
INTERACTIVE DEMO
Let’s define an ATOMIC VECTOR OF NUMBERS
- To create a vector USE THE c() FUNCTION (c() is combine; use ?c)

> x <- c(10, 12, 45, 33)
> x
[1] 10 12 45 33

Let’s check the data type, and what kind of structure we have

> typeof(x)
[1] "double"
> length(x)
[1] 4
> str(x)
 num [1:4] 10 12 45 33

This is a little cryptic as output
- We can see from typeof() that the vector contains the double type
- The output of str() tells us:
  - it’s a numeric (num) vector - which includes double and integer datatypes
  - there are four elements [1:4] in the vector
  - the first few datapoint in the vector
str() tells us that the cats$coat column is a vector, too:

> str(cats$coat)
 chr [1:3] "calico" "black" "tabby"

Coercion (1)

INTERACTIVE DEMO
Given what we’ve done so far, what do you think the following will produce when we use typeof()?
- PAUSE FOR STUDENT SUGGESTIONS

> quiz_vector <- c(2,6,'3')
> typeof(quiz_vector)
[1] "character"

Here, R has enforced that the type of the vector is character (string), because we can always represent numbers as strings, but we can’t always represent strings as numbers
PAUSE: NEXT CALLOUTS
This is called type coercion and can cause surprises in your code
- It is a key reason why you need to be aware of the basic data types and how R interprets them.
INTERACTIVE DEMO
Consider these two vectors

> coercion_vector <- c('a', TRUE)
> coercion_vector
[1] "a"    "TRUE"
> another_coercion_vector <- c(0, TRUE)
> another_coercion_vector
[1] 0 1

What do you expect their datatypes to be?

> typeof(coercion_vector)
[1] "character"
> typeof(another_coercion_vector)
[1] "double"

Coercion (2)

Coercion is what happens when you CONVERT ONE DATA TYPE INTO ANOTHER
If R thinks it needs to, it will COERCE DATA IMPLICITLY without telling you
There is a set order for coercion
- logical can be coerced to integer, but integer cannot be coerced to logical
- That’s because integer can describe all logical values, but not vice versa
- Everything can be represented as a character, so that’s the fallback position for R
IF THERE’S A FORMATTING PROBLEM IN YOUR DATA, R MIGHT CONVERT THE TYPE TO COPE
- R will choose the simplest data type that can represent all items in the vector
INTERACTIVE DEMO IN CONSOLE More useful things to do with vectors
You can (usually) COERCE VECTORS MANUALLY with as.<type>()

> x
[1] 10 12 45 33
> as.character(x)
[1] "10" "12" "45" "33"
> as.complex(x)
[1] 10+0i 12+0i 45+0i 33+0i
> as.logical(x)
[1] TRUE TRUE TRUE TRUE

Surprising things can happen when R forces one data type into another.
If your data doesn’t look how you expect it to, type coercion may be to blame
- Check your data formatting (is there an accidental string/character?)
Let’s look at our cats dataframe again

> cats
    coat weight likes_catnip
1 calico    2.1            1
2  black    5.0            0
3  tabby    3.2            1
> typeof(cats$likes_catnip)
[1] "integer"

The type of the likes_catnip column is recorded as an integer, but we want logical TRUE/FALSE values.
- We can use the as.logical() function to change this

> cats$likes_catnip <- as.logical(cats$likes_catnip)
> cats
    coat weight likes_catnip
1 calico    2.1         TRUE
2  black    5.0        FALSE
3  tabby    3.2         TRUE
> str(cats)
'data.frame': 3 obs. of  3 variables:
 $ coat        : chr  "calico" "black" "tabby"
 $ weight      : num  2.1 5 3.2
 $ likes_catnip: logi  TRUE FALSE TRUE

Lists

lists are data structures like vectors, EXCEPT THEY CAN HOLD ANY DATA TYPE
- They are not constrained to atomic types
- They do not coerce their contents’ datatypes
Let’s create a new list using the list() function

> l <- list(1, 'a', TRUE, seq(2, 5))
> length(l)
[1] 4
> l
[[1]]
[1] 1

[[2]]
[1] "a"

[[3]]
[1] TRUE

[[4]]
[1] 2 3 4 5

Individual elements in the list are identified with DOUBLE SQUARE BRACKETS
- There are four elements
- [[1]] is the number 1
- [[2]] is the character "a"
- [[3]] is the logical value TRUE
- [[4]] is the vector of values from 2 to 5
We can extract a single element from the list with the double square bracket notation

> l[[1]]
[1] 1
> l[[4]]
[1] 2 3 4 5

Using the str() function we can see the datatypes of all the elements in the list

> str(l)
List of 4
 $ : num 1
 $ : chr "a"
 $ : logi TRUE
 $ : int [1:4] 2 3 4 5

The elements of a list can also have names
- We specify the name when we create the list

> l_named <- list(a = "SWC", b = 1:4)
> l_named
$a
[1] "SWC"

$b
[1] 1 2 3 4

We can use the name of each element to retrieve it, with the $ notation:

> l_named$a
[1] "SWC"
> l_named$b
[1] 1 2 3 4

But it’s still a list like any other, and we can use the double square bracket notation.

> l_named[[1]]
[1] "SWC"
> l_named[[2]]
[1] 1 2 3 4
> str(l_named)
List of 2
 $ a: chr "SWC"
 $ b: int [1:4] 1 2 3 4

Let’s Look At A Data Frame

We didn’t go into detail about the cats dataframe we created at the start of this episode.
- But let’s look at it more closely

> cats
    coat weight likes_catnip
1 calico    2.1         TRUE
2  black    5.0        FALSE
3  tabby    3.2         TRUE
> typeof(cats)
[1] "list"
> cats[[2]]
[1] 2.1 5.0 3.2
> typeof(cats$weight)
[1] "double"

So cats is a list, and each element in the list is a vector
PAUSE: NEXT CALLOUT
But cats is a special kind of list - a data.frame - where all the vectors have the same length.
- We can see that this is a special kind of list by using the class() function

> class(cats)
[1] "data.frame"
> class(l)
[1] "list"

The class data.frame represents a standard way of organising data:
- Each row is an observation
- Each column is a variable
- The data frame represents a series of observations

Load Episode Data

DEMO IN SCRIPT
DOWNLOAD DATA
- Use the link from the Etherpad document
- Place the file in data/
CREATE A NEW SCRIPT
- Call it gapminder
- Add the code
- Use read.table
- The data is in CSV format
- We need to provide a data source (here, a file), the separator character, and whether there’s a header row

# Load gapminder data from a local file
gapminder <- read.table("data/gapminder_data.csv", sep=",", header=TRUE)

RUN THE SCRIPT (use Source)
CHECK THE DATA IN THE Environment TAB
- Click on gapminder in Environment tab.
- NOTE COLUMNS

Investigating `gapminder`

Now we’ve loaded our data, let’s take a look at it
DEMO IN CONSOLE
- 1704 rows, 6 columns
- Investigate types of columns
- POINT OUT THAT THE TYPE OF A COLUMN IS INTEGER IF IT’S A FACTOR
- LENGTH OF A DATAFRAME IS THE NUMBER OF COLUMNS
It’s always useful to get an initial understanding of your data with the str() function.

> str(gapminder)
'data.frame': 1704 obs. of  6 variables:
 $ country  : Factor w/ 142 levels "Afghanistan",..: 1 1 1 1 1 1 1 1 1 1 ...
 $ year     : int  1952 1957 1962 1967 1972 1977 1982 1987 1992 1997 ...
 $ pop      : num  8425333 9240934 10267083 11537966 13079460 ...
 $ continent: Factor w/ 5 levels "Africa","Americas",..: 3 3 3 3 3 3 3 3 3 3 ...
 $ lifeExp  : num  28.8 30.3 32 34 36.1 ...
 $ gdpPercap: num  779 821 853 836 740 ...

The summary() function can also be useful
- With dataframes, this gives a numeric, tabular, or descriptive summary of each column.

> summary(gapminder)
        country          year           pop               continent      lifeExp
 Afghanistan:  12   Min.   :1952   Min.   :6.001e+04   Africa  :624   Min.   :23.60
 Albania    :  12   1st Qu.:1966   1st Qu.:2.794e+06   Americas:300   1st Qu.:48.20
 Algeria    :  12   Median :1980   Median :7.024e+06   Asia    :396   Median :60.71
 Angola     :  12   Mean   :1980   Mean   :2.960e+07   Europe  :360   Mean   :59.47
 Argentina  :  12   3rd Qu.:1993   3rd Qu.:1.959e+07   Oceania : 24   3rd Qu.:70.85
 Australia  :  12   Max.   :2007   Max.   :1.319e+09                  Max.   :82.60
 (Other)    :1632
   gdpPercap
 Min.   :   241.2
 1st Qu.:  1202.1
 Median :  3531.8
 Mean   :  7215.3
 3rd Qu.:  9325.5
 Max.   :113523.1

We can also inspect individual columns of the data.

> typeof(gapminder$year)
[1] "integer"
> typeof(gapminder$country)
[1] "integer"

This looks a little weird: why should the country be an integer?
- Let’s investigate further with str()

> str(gapminder$country)
 Factor w/ 142 levels "Afghanistan",..: 1 1 1 1 1 1 1 1 1 1 ...

The country column has been read in as a factor
- A factor is a data structure that represents categorical data.
- We can see this in the str() output we got, as well: both country and continent were read in as factors.
- This is fine, and is what we actually want.
We can ask about the dimensions of the dataframe with dim()

> dim(gapminder)
[1] 1704    6

So there are 1704 rows and 6 columns
What does length() produce:

> length(gapminder)
[1] 6

Remember that a dataframe is a list of vector columns, so its length is the number of elements in the list.
- There are six columns, so the length of the dataframe is 6.
We can ask specifically for the number of rows and columns, and for other information.
We can also use head() to summarise the dataframe.

> nrow(gapminder)
[1] 1704
> ncol(gapminder)
[1] 6
> colnames(gapminder)
[1] "country"   "year"      "pop"       "continent" "lifeExp"   "gdpPercap"
> head(gapminder)
      country year      pop continent lifeExp gdpPercap
1 Afghanistan 1952  8425333      Asia  28.801  779.4453
2 Afghanistan 1957  9240934      Asia  30.332  820.8530
3 Afghanistan 1962 10267083      Asia  31.997  853.1007
4 Afghanistan 1967 11537966      Asia  34.020  836.1971
5 Afghanistan 1972 13079460      Asia  36.088  739.9811

Data Frame Manipulation With `dplyr`

Learning Objectives (Data Frames)

You’re going to learn to manipulate data.frames with the six verbs of dplyr
select()
filter()
group_by()
summarize()
mutate()
%>% (pipe)

What and Why is `dplyr`?

dplyr is a package in the TIDYVERSE; it exists to enable rapid analysis of data by groups
- For example, if we wanted numerical (rather than graphical) analysis of the gapminder data by continent, we’d use dplyr
- It enables group-level analyses without using repetitive code
AVOIDING REPETITION IMPROVES YOUR CODE
- More robust
- More readable
- More reproducible

Split-Apply-Combine

The general principle dplyr supports is called SPLIT-APPLY-COMBINE
We have a dataset with several groups in a variable (column x)
- For example, each patient in our messy data might be a “group”
We want to perform the same operation on each group, independently - take a mean of y for each group, for example
- So we SPLIT the data into groups, on x
- Then we APPLY the operation (take the mean for each group)
- Then we COMBINE the results into a new table

`select()` - Interactive Demo**

DEMO IN CONSOLE
- Import dplyr

> library(dplyr)

The select() verb SELECTS COLUMNS
- DEMO IN CONSOLE
- If we wanted to select only year, country and GDP data from gapminder
- Specify: data, then columns

> head(select(gapminder, year, country, gdpPercap))
  year     country gdpPercap
1 1952 Afghanistan  779.4453
2 1957 Afghanistan  820.8530
3 1962 Afghanistan  853.1007
4 1967 Afghanistan  836.1971
5 1972 Afghanistan  739.9811
6 1977 Afghanistan  786.1134

Here, we applied a function, but we can also ‘PIPE’ DATA FROM ONE VERB TO ANOTHER
- These work like pipes in the shell
- SPECIAL PIPE SYMBOL: %>%
- Specify only columns

> gapminder %>% select(year, country, gdpPercap) %>% head()
  year     country gdpPercap
1 1952 Afghanistan  779.4453
2 1957 Afghanistan  820.8530
3 1962 Afghanistan  853.1007
4 1967 Afghanistan  836.1971
5 1972 Afghanistan  739.9811
6 1977 Afghanistan  786.1134

`filter()`

filter() selects rows on the basis of some condition, or combination of conditions
- We can use it as a function, with pipes
DEMO IN CONSOLE

> head(filter(gapminder, continent=="Europe"))
  country year     pop continent lifeExp gdpPercap
1 Albania 1952 1282697    Europe   55.23  1601.056
2 Albania 1957 1476505    Europe   59.28  1942.284
3 Albania 1962 1728137    Europe   64.82  2312.889
4 Albania 1967 1984060    Europe   66.22  2760.197
5 Albania 1972 2263554    Europe   67.69  3313.422
6 Albania 1977 2509048    Europe   68.93  3533.004

DEMO IN SCRIPT (gapminder.R)
- One advantage of pipes is that they make chaining verbs together MORE READABLE
- END THE LINES WITH THE PIPE SYMBOL so R knows that there’s a continuation
- Run the lines and check the output in Environment

# Select gdpPercap by country and year, only for Europe
eurodata <- gapminder %>%
              filter(continent == "Europe") %>%
              select(year, country, gdpPercap)

Challenge

# Select life expectancy by country and year, only for Africa
> afrodata <- gapminder %>%
  filter(continent == "Africa") %>%
  select(year, country, lifeExp)
> nrow(afrodata)
[1] 624

`group_by()`

The group_by() verb SPLITS data.frames INTO GROUPS ON A VARIABLE/COLUMN PROPERTY
DEMO IN CONSOLE
- It returns a tibble - a table with extra metadata describing the groups in the table

> group_by(gapminder, continent)
# A tibble: 1,704 x 6
# Groups:   continent [5]
       country  year      pop continent lifeExp gdpPercap
        <fctr> <int>    <dbl>    <fctr>   <dbl>     <dbl>
 1 Afghanistan  1952  8425333      Asia  28.801  779.4453
 2 Afghanistan  1957  9240934      Asia  30.332  820.8530
 3 Afghanistan  1962 10267083      Asia  31.997  853.1007
 4 Afghanistan  1967 11537966      Asia  34.020  836.1971
 5 Afghanistan  1972 13079460      Asia  36.088  739.9811
 6 Afghanistan  1977 14880372      Asia  38.438  786.1134
 7 Afghanistan  1982 12881816      Asia  39.854  978.0114
 8 Afghanistan  1987 13867957      Asia  40.822  852.3959
 9 Afghanistan  1992 16317921      Asia  41.674  649.3414
10 Afghanistan  1997 22227415      Asia  41.763  635.3414
# ... with 1,694 more rows

`summarize()`

The combination of group_by() and summarize() is very powerful
- We can CREATE NEW VARIABLES using functions that repeat for each group
Here, we’ve split the original table into three groups, and now CREATE A NEW VARIABLE mean_b THAT IS FILLED BY CALCULATING THE MEAN OF b
DEMO IN SCRIPT
- We use the same principle to calculate mean GDP per continent

> # Produce table of mean GDP by continent
> gapminder %>%
+     group_by(continent) %>%
+     summarize(meangdpPercap=mean(gdpPercap))
# A tibble: 5 x 2
  continent meangdpPercap
     <fctr>         <dbl>
1    Africa      2193.755
2  Americas      7136.110
3      Asia      7902.150
4    Europe     14469.476
5   Oceania     18621.609

Challenge 13

IN THE SCRIPT

# Find average life expectancy by nation
avg_lifexp_country <- gapminder %>%
  group_by(country) %>%
  summarize(meanlifeExp=mean(lifeExp))

IN THE CONSOLE

> avg_lifexp_country %>% filter(meanlifeExp == min(meanlifeExp))
# A tibble: 1 × 2
  country      meanlifeExp
  <chr>              <dbl>
1 Sierra Leone        36.8
> avg_lifexp_country %>% filter(meanlifeExp == max(meanlifeExp))
# A tibble: 1 × 2
  country meanlifeExp
  <chr>         <dbl>
1 Iceland        76.5

`count()` and `n()`

Two other useful functions are related to summarize()
- count() reports a new table of counts by group
- n() is used to represent the count of rows, when calculating new values in summarize()
DEMO IN CONSOLE
NOTE: standard error is (std dev)/sqrt(n)

> gapminder %>% filter(year == 2002) %>% count(continent, sort = TRUE)
# A tibble: 5 x 2
  continent     n
     <fctr> <int>
1    Africa    52
2      Asia    33
3    Europe    30
4  Americas    25
5   Oceania     2
> gapminder %>% group_by(continent) %>% summarize(se_lifeExp = sd(lifeExp)/sqrt(n()))
# A tibble: 5 x 2
  continent se_lifeExp
     <fctr>      <dbl>
1    Africa  0.3663016
2  Americas  0.5395389
3      Asia  0.5962151
4    Europe  0.2863536
5   Oceania  0.7747759

`mutate()`

mutate() CALCULATES NEW VARIABLES (COLUMNS) ON THE BASIS OF EXISTING COLUMNS
DEMO IN SCRIPT
- Say we want to calculate the total GDP of each nation, each year, in $bn
- We’d multiply the GDP per capita by the total population, and divide by 1bn
INSPECT THE OUTPUT
- We have a new data table, which is the gapminder data, plus an extra column

# Calculate GDP in $billion
gdp_bill <- gapminder %>%
  mutate(gdp_billion = gdpPercap * pop / 10^9)

WE CAN CHAIN ALL THESE OPERATIONS TOGETHER WITH PIPES
We can calculate several summaries in a single summarize() command
We can use the output of mutate() in the summarize() command
DEMO IN SCRIPT
- We’re going to calculate the total (and standard deviation) of GDP per continent, per year
- Calculate total GDP first
- Group by continent and year
- Summarise mean and sd of GDP per capita, and total GDP
INSPECT THE OUTPUT

# Calculate total/sd of GDP by continent and year
gdp_bycontinents_byyear <- gapminder %>%
  mutate(gdp_billion=gdpPercap*pop/10^9) %>%
  group_by(continent,year) %>%
  summarize(mean_gdpPercap=mean(gdpPercap),
            sd_gdpPercap=sd(gdpPercap),
            mean_gdp_billion=mean(gdp_billion),
            sd_gdp_billion=sd(gdp_billion))

`ifelse()`

ifelse() IS A FILTER THAT CAN BE USED WITH MUTATE TO CALCULATES NEW VARIABLES (COLUMNS) ON THE BASIS OF EXISTING COLUMNS ONLY IF SOME CONDITION IS MET
DEMO IN SCRIPT
- Say we want to calculate the total GDP of each nation, each year, in $bn BUT ONLY FOR COUNTRIES OVER 10mn PEOPLE

gdp_billion_large_countries <- gapminder %>%
  mutate(gdp_billion_large = ifelse(pop > 10e6,
                                    gdpPercap * pop / 10^9,
                                    NA))

INSPECT THE OUTPUT
- We have a new data table, which is the gapminder data, plus an extra column
Similarly, we can scale GDP only in those cases where life expectancy for a nation is over 40

gdp_future_bycontinents_byyear_high_lifeExp <- gapminder %>%
    mutate(gdp_futureExpectation = ifelse(lifeExp > 40, gdpPercap * 1.5, gdpPercap)) %>%
    group_by(continent, year) %>%
    summarize(mean_gdpPercap = mean(gdpPercap),
              mean_gdpPercap_expected = mean(gdp_futureExpectation))

Tidy Data

Why Tidy Data?

Data cleaning/processing is not just a first step - it must be repeated many time over the course of an analysis
- new data, new ideas, etc. turn up as you’re working
About 80% of the effort of data analysis is cleaning and preparing data for analysis
The principles of tidy data provide a standard way to organise data values within a dataset
- “Tidy datasets are all alike, but every messy dataset is messy in its own way”

An Untidy Dataset (1)

Here’s a dataset like you might receive it from a colleague
It’s a RECTANGULAR TABLE
- Made up of ROWS and COLUMNS, just like the data you’ve been working with
Each row describes a treatment
Each column gives the results for a different individual, for each treatment
Thinking about how our dataframes are structured, there should be one row per observation.
- But here the observations are the people
- So maybe we could transpose the rows and columns so that the people are the rows?

An Untidy Dataset (2)

So we’ve transposed the rows and columns of the table
The data is the same
The layout is different
Now we have one row per observation, and we have one column per variable (treatments A and B), and that’s what we want, isn’t it?
PAUSE: NEW CALLOUT
But the data doesn’t have to be structured this way.
- In fact, this isn’t a very good way to structure data for many analyses.
To understand what this means, AND WHY IT IS UNTIDY DATA, we need to consider some data semantics.

Data Semantics

We need to define three terms
A dataset, like the one shown, is a collection of VALUES
Each value belongs to a variable, and to an observation
A VARIABLE is something that can change or vary
- They may be values that measure the same underlying attribute, such as height, temperature, or some kind of output result
- They may be experimental conditions under a researcher’s control, such as a treatment, how long that treatment is applied, or other experimental settings
An OBSERVATION is a collection of values measured across all variables for the same individual or unit
- The unit is often a person, a collective group like a religion or company, or a physical item like a reactor vessel

Challenge (2min)

So for our first messy dataset, how would you describe the rows and columns of the table?
- Are they observations, or variables, or neither?
THE ROWS AND COLUMNS IN THE MESSY DATA ARE NEITHER OBSERVATIONS NOR VARIABLES

A Tidy Dataset (1)

The dataset contains 18 values:
- six observations of three variables
The variables are:
- PERSON: John, Mary and Jane
- TREATMENT: A or B
- RESULT: NA, 16, 3, 2, 11, 1
Each OBSERVATION includes values for all three variables

A Tidy Dataset (2)

Here is the dataset represented in tidy form
You can see each variable has its own column
Each observation has one value per column
- Note: Missing data counts as a value

Tidy Data (2)

Tidy data is a STANDARD way of structuring a dataset, but it is not the only way, or always the best way
- It does make it easy to extract the variables you need
- It is also very well suited to R because it supports vectorisation (which you saw earlier)
In Tidy Data:
- Each variable forms a column
- Each observation forms a row
Most of the data you receive is unlikely to be Tidy, so you’ll probably need to clean it
And MESSY DATA CAN BE USEFUL
- If your design is completely crossed: e.g. every individual tries every medicine
  - Messy Data (rows=patients, columns=medicines) is compact
    - Also useful if matrix operations are appropriate
INTERACTIVE DEMO
- Show that the gapminder data is in an intermediate format
- Three ID variables (continent, country, year)
- Three observation variables (pop, lifeExp, gdpPercap)
- This intermediate form can be preferable; there is no advantage to having a single “observation” column, here
IN THE CONSOLE
- Each column in the gapminder dataset is a variable
- Each row is a set of values: one per variable, comprising a single observation for a combination of country and year
WE CAN USE DPLYR DATA METHODS ON THIS DATASET

> head(gapminder)
      country year      pop continent lifeExp gdpPercap
1 Afghanistan 1952  8425333      Asia  28.801  779.4453
2 Afghanistan 1957  9240934      Asia  30.332  820.8530
3 Afghanistan 1962 10267083      Asia  31.997  853.1007
4 Afghanistan 1967 11537966      Asia  34.020  836.1971
5 Afghanistan 1972 13079460      Asia  36.088  739.9811
6 Afghanistan 1977 14880372      Asia  38.438  786.1134

Long v Wide

We often refer to datasets as being “long” or “wide”
LONG datasets have one row per observation, and one column per variable
WIDE datasets might have multiple arrangements
Wide datasets tend to be easier for humans to read
- Quite a lot of the time, we tend to record and share datasets in wide format.
BUT MANY R FUNCTIONS ARE DESIGNED TO WORK WITH LONG DATA
- Some plotting functions work better with wide data, though
- The purely long format can require additional grouping operations (like group_by()), and it can be more convenient to have an intermediate form like the gapminder data.

`gapminder` Wide Dataset

We’ve been using the nicely-formatted gapminder data to make our lives easier.
THE DATA YOU RECEIVE IN A RESEARCH CONTEXT WILL NOT USUALLY BE SO NICELY-FORMATTED
Let’s load in the wide-format gapminder data and take a look at it.

> gap_wide <- read.csv("data/gapminder_wide.csv", stringsAsFactors = FALSE)
> str(gap_wide)
'data.frame': 142 obs. of  38 variables:
 $ continent     : chr  "Africa" "Africa" "Africa" "Africa" ...
 $ country       : chr  "Algeria" "Angola" "Benin" "Botswana" ...
 $ gdpPercap_1952: num  2449 3521 1063 851 543 ...
 $ gdpPercap_1957: num  3014 3828 960 918 617 ...
 $ gdpPercap_1962: num  2551 4269 949 984 723 ...
 $ gdpPercap_1967: num  3247 5523 1036 1215 795 ...
 $ gdpPercap_1972: num  4183 5473 1086 2264 855 ...
 $ gdpPercap_1977: num  4910 3009 1029 3215 743 ...
 $ gdpPercap_1982: num  5745 2757 1278 4551 807 ...
 $ gdpPercap_1987: num  5681 2430 1226 6206 912 ...
 $ gdpPercap_1992: num  5023 2628 1191 7954 932 ...
 $ gdpPercap_1997: num  4797 2277 1233 8647 946 ...
 $ gdpPercap_2002: num  5288 2773 1373 11004 1038 ...
 $ gdpPercap_2007: num  6223 4797 1441 12570 1217 ...
 $ lifeExp_1952  : num  43.1 30 38.2 47.6 32 ...
 $ lifeExp_1957  : num  45.7 32 40.4 49.6 34.9 ...
 $ lifeExp_1962  : num  48.3 34 42.6 51.5 37.8 ...
 $ lifeExp_1967  : num  51.4 36 44.9 53.3 40.7 ...
 $ lifeExp_1972  : num  54.5 37.9 47 56 43.6 ...
 $ lifeExp_1977  : num  58 39.5 49.2 59.3 46.1 ...
 $ lifeExp_1982  : num  61.4 39.9 50.9 61.5 48.1 ...
 $ lifeExp_1987  : num  65.8 39.9 52.3 63.6 49.6 ...
 $ lifeExp_1992  : num  67.7 40.6 53.9 62.7 50.3 ...
 $ lifeExp_1997  : num  69.2 41 54.8 52.6 50.3 ...
 $ lifeExp_2002  : num  71 41 54.4 46.6 50.6 ...
 $ lifeExp_2007  : num  72.3 42.7 56.7 50.7 52.3 ...
 $ pop_1952      : num  9279525 4232095 1738315 442308 4469979 ...
 $ pop_1957      : num  10270856 4561361 1925173 474639 4713416 ...
 $ pop_1962      : num  11000948 4826015 2151895 512764 4919632 ...
 $ pop_1967      : num  12760499 5247469 2427334 553541 5127935 ...
 $ pop_1972      : num  14760787 5894858 2761407 619351 5433886 ...
 $ pop_1977      : num  17152804 6162675 3168267 781472 5889574 ...
 $ pop_1982      : num  20033753 7016384 3641603 970347 6634596 ...
 $ pop_1987      : num  23254956 7874230 4243788 1151184 7586551 ...
 $ pop_1992      : num  26298373 8735988 4981671 1342614 8878303 ...
 $ pop_1997      : num  29072015 9875024 6066080 1536536 10352843 ...
 $ pop_2002      : int  31287142 10866106 7026113 1630347 12251209 7021078 15929988 4048013 8835739 614382 ...
 $ pop_2007      : int  33333216 12420476 8078314 1639131 14326203 8390505 17696293 4369038 10238807 710960 ...

ALSO VIEW IN RSTUDIO
This is very wide data and it looks like it would be a bit of a nightmare to do the kinds of analyses we have been doing, with the data in this format.

Pivot: Wide to Long

We want to convert this wide format that’s difficult to work with to our nice, longer, intermediate layout.
TO DO THIS WE USE THE pivot_longer() FUNCTION FROM dplyr/tidyverse
- This makes datasets longer by increasing the number of rows and decreasing the number of columns
- You may be familiar with “pivot tables” from Excel, which are similar.
It works like the image shows
- We define the dataset we want to pivot
- We say which columns we want to convert from wide to long format in the cols variable
  - The pivot_longer() function effectively splits the table by these columns
  - The column name then gets converted to its own, new column, but the values are kept
- We specify the names of the new “name” and “value” columns wiht names_to and values_to.
For the gapminder data, we want to pivot all columns that start with pop, lifeExp or gdpPercent
- We’ll put the column names into a column called obstype_year
- We’ll put the values into a column called obs_values

> gap_long <- gap_wide %>%
+     pivot_longer(
+         cols = c(starts_with('pop'), starts_with('lifeExp'), starts_with('gdpPercap')),
+         names_to = "obstype_year", values_to = "obs_values"
+     )
> str(gap_long)
tibble [5,112 × 4] (S3: tbl_df/tbl/data.frame)
 $ continent   : chr [1:5112] "Africa" "Africa" "Africa" "Africa" ...
 $ country     : chr [1:5112] "Algeria" "Algeria" "Algeria" "Algeria" ...
 $ obstype_year: chr [1:5112] "pop_1952" "pop_1957" "pop_1962" "pop_1967" ...
 $ obs_values  : num [1:5112] 9279525 10270856 11000948 12760499 14760787 ...

This gives us a long format table with four columns
BUT IT’S NOT QUITE WHAT WE WANT, BECAUSE WE HAVE TWO KINDS OF DATA COMBINED IN THE obstype_year COLUMN
- We want to split year into its own column.

`separate()`

THE separate() FUNCTION SPLITS THE CONTENTS OF A SINGLE COLUMN INTO MULTIPLE NEW COLUMNS
- We want to split the year information from every cell in the obstype_year column into its own new column.
The separate() function needs to know:
- dataframe it’s working on
- the column it’s splitting
- the names of the new columns it’s making
- the character it’s splitting the cell content on
We split the obstype_year column into two columns called obs_type and year, on the underscore separator "_".

> gap_long <- gap_long %>% separate(obstype_year, into = c('obs_type', 'year'), sep = "_")

As the year at this point is still a character string, we change the datatype with as.integer and take a look at the new dataframe.

> gap_long$year <- as.integer(gap_long$year)
> str(gap_long)
tibble [5,112 × 5] (S3: tbl_df/tbl/data.frame)
 $ continent : chr [1:5112] "Africa" "Africa" "Africa" "Africa" ...
 $ country   : chr [1:5112] "Algeria" "Algeria" "Algeria" "Algeria" ...
 $ obs_type  : chr [1:5112] "pop" "pop" "pop" "pop" ...
 $ year      : int [1:5112] 1952 1957 1962 1967 1972 1977 1982 1987 1992 1997 ...
 $ obs_values: num [1:5112] 9279525 10270856 11000948 12760499 14760787 ...

THIS IS STILL NOT QUITE WHERE WE WANT IT
- There are three types of observation combined in obs_type and obs_values and it would be convenient to split them into new columns

Pivot: Long to Wide

We want to convert this long format into a slightly wider intermediate layout, for convenience.
There is a companion function to pivot_longer() called pivot_wider() that we use for this.
- It’s essentially the reverse of pivot_longer()
THE pivot_wider() FUNCTION SPLITS THE TABLE UP BY VALUES IN THE COLUMN OF “NAMES”
- It then changes the name of the “VALUES” column to reflect the value in the “NAMES” column for each split.
- Finally, it recombines the columns into a single table on the basis of the ID columns
We want to do this with the gapminder data by using the obs_type column for the names, and the obs_values column for the values.

> gap_normal <- gap_long %>% pivot_wider(names_from = obs_type, values_from = obs_values)
> str(gap_normal)
tibble [1,704 × 6] (S3: tbl_df/tbl/data.frame)
 $ continent: chr [1:1704] "Africa" "Africa" "Africa" "Africa" ...
 $ country  : chr [1:1704] "Algeria" "Algeria" "Algeria" "Algeria" ...
 $ year     : int [1:1704] 1952 1957 1962 1967 1972 1977 1982 1987 1992 1997 ...
 $ pop      : num [1:1704] 9279525 10270856 11000948 12760499 14760787 ...
 $ lifeExp  : num [1:1704] 43.1 45.7 48.3 51.4 54.5 ...
 $ gdpPercap: num [1:1704] 2449 3014 2551 3247 4183 ...

And we can see that this has restored the intermediate form of the data that was so useful to us earlier.

Challenge (5min)

Using gap_long, calculate the mean life expectancy, population, and gdpPercap for each continent. Hint: use the group_by() and summarize() functions we learned in the dplyr lesson

gap_long %>% group_by(continent, obs_type) %>%
   summarize(means=mean(obs_values))

Data Structures and Data Frames

Preflight

Learning Questions

Learning Objectives

Data Types and Structures in R

What Data Types Do You Expect?

Data Types in R

A Quick Note About Dataframes

Vectors

Coercion (1)

Coercion (2)

Lists

Let’s Look At A Data Frame

Load Episode Data

Investigating gapminder

Data Frame Manipulation With dplyr

Learning Objectives (Data Frames)

What and Why is dplyr?

Split-Apply-Combine

select() - Interactive Demo**

filter()

Challenge

group_by()

summarize()

Challenge 13

count() and n()

mutate()

ifelse()

Tidy Data

Why Tidy Data?

An Untidy Dataset (1)

An Untidy Dataset (2)

Data Semantics

Challenge (2min)

A Tidy Dataset (1)

A Tidy Dataset (2)

Tidy Data (2)

Long v Wide

gapminder Wide Dataset

Pivot: Wide to Long

separate()

Pivot: Long to Wide

Challenge (5min)

Data Types and Structures in `R`

Data Types in `R`

Investigating `gapminder`

Data Frame Manipulation With `dplyr`

What and Why is `dplyr`?

`select()` - Interactive Demo**

`filter()`

`group_by()`

`summarize()`

`count()` and `n()`

`mutate()`

`ifelse()`

`gapminder` Wide Dataset

`separate()`
